Parameters
model |
input speed r/min |
reduction ratio (i ) |
transfer ability kW/r/min |
Rated thrust (kN) |
Center distance (mm ) |
length x width x height (mm ) |
net weight (kg ) |
Manipulation type |
Link flywheel |
connection housing |
Input and output steering when following the train |
HCQ300 |
1000-2300 |
1.06 1.21 1.36 1.46 1.74 2.05 |
0.250 |
40 |
203 |
630 ×521 ×680 |
370 |
Push-pull flexible shaft Electronic control |
SAE18 16 14 |
SAE0 1 |
on the contrary |
2.38 |
0.235 |
on the contrary |
|||||||||
2.55 |
0.23 |
||||||||||
HCA300 ( tilt 10 °) |
1000-2300 |
1.52 1.96 2.50 |
0.250 |
40 |
278 |
620 ×585 ×753 |
370 |
Push-pull flexible shaft Electronic control |
SAE18 16 14 |
SAE0 1 |
on the contrary |
2.95 |
0.235 |
on the contrary |
|||||||||
HCA301 ( Inclination 5 °) |
1000-2300 |
1.50 1.96 2.57 |
0.250 |
40 |
265 |
618 × 585 × 824 |
370 |
Push-pull flexible shaft Electronic control |
SAE18 16 14 |
SAE0 1 |
on the contrary |
2.95 |
0.235 |
||||||||||
HCA302 ( tilt angle 7 °) |
1000-2300 |
1.52 1.96 2.57 |
0.25 |
40 |
267.5 |
560 ×585 ×764 (without bracket) |
|
Push-pull flexible shaft Electronic control |
SAE 14 |
SAE 1 |
on the contrary |
2.95 |
0.235 |
